Srpski језик Farmland Towable Backhoe Mini Excavator is a versatile piece of equipment designed for a variety of excavation tasks. Its towing function allows for easy transportation and is suitable for both residential and commercial projects. Equipped with a powerful engine, this mini excavator performs efficiently, allowing users to tackle a variety of excavation and landscaping activities.
Farmland Towable Backhoe Mini Excavator is a small, compact excavator designed for small farms and rural properties. It is designed to be towed behind a tractor or other vehicle to ensure portability and flexibility in different locations.
UNIQUE SELLING POINT:Fully hydraulic system
Machinery Test Report:Provided
Video outgoing-inspection:Provided
Warranty of core components:1 Year
Core Components:Pressure vessel, Engine, Gearbox
Moving Type:Wheel Loader
Dimension(Long * Breadth * High):4500/1550/2600mm
These mini excavators are typically equipped with hydraulic arms and buckets and can be used for a variety of tasks, including trenching, digging ponds, planting trees, and moving small amounts of dirt, gravel, or other materials. The backhoe itself is designed with an adjustable arm and bucket, making it easy to reach different angles and depths.
| Backhoe loader 2OL Loader technical parameters | ||
| Overall dimension | mm | 4500/1550/2600 |
| Chief of transport | mm | 4600 |
| Total transport width | mm | 1550 |
| Total transport height | mm | 2600 |
| Minimum ground clearance | mm | 260 |
| Working weight | kg | 3500 |
| Ground specific voltage | kpa | 38 |
| Tyre type | 12-16.5 | |
| Distance between centers | mm | 1250 |
| wide | mm | 230 |
| Ground length | mm | 305 |
| property | ||
| Maximum lifting height | mm | 3500-3900 |
| Maximum handling height | mm | 2400-2800 |
| Climbing Angle (degree) | 25° | |
| Travel speed | km/h | 25-35 |
| A surname | m | 0.5 |
| Bucket width | mm | 1500 |
| engine | ||
| Model number | 490 | |
| power | kw/rpm | 37/2400 |
| Digging arm technical parameters | ||
| Bucket capacity | m3 | 0.04 |
| Bucket width | mm | 450 |
| Boom length | mm | 1823 |
| Rod length | mm | 1130 |
| property | ||
| Turning speed | rpm1 | 10 |
| Bucket digging force | KN | 15.2 |
| Bucket rod digging force | KN | 8.7 |
| Maximum tractive effort | KN | 12.5 |
| Scope of operation | ||
| Maximum excavation radius | mm | 3920 |
| Maximum excavation radius of stopping surface | mm | 3820 |
| Maximum digging depth | mm | 2140 |
| Maximum excavation height | mm | 3330 |
| Maximum unloading height | mm | 2440 |
| Boom offset (left/right) | Mm | 240/460 |


FAQ
1. What's the MOQ (Minimum Order Quantity)?
A: 1 unit.
2. Can support massive production (OEM or ODM), even for one piece?
A: Definitely acceptable to OEM or ODM. We support customization, even for one piece. As we know, the customized prototypes will be charged accordingly and need you provide the design artwork. It's acceptable to you to select a current product from our catalog or seek engineering assistance for your application, you can reach jack about your sourcing needs.
3. What's the Payment Terms?
A: Alibaba Trade Assurance online or T/T offline.
4. What's the shipping way and delivery time?
A: Normally by Sea, FOB (QingDao), CFR, CIF, taking 20-50 days according to your address and order quantity after the ship leaves China. If urgent, Air shipping for small machine, taking 5-15 days according to your details.
5. What if we want it to be delivered to my door?
A: Of course, it can be. If you're quite closed to the port, we recommend you to pick it up directly, you will save A LOT OF Money in this way!!! If not so closed, we recommend you to find an Inland Transportation Company by yourself to handle the import procedures, we will assist him at the same time; we can also find an agency for you, but we don't recommend it because the toll will be very high, not cost-efficient. During the assistance, we will not charge any Intermediate fees or additional service fees other than the freight.
6. What about the production time?
A: Generally within 7-10 workdays after receiving the payment for small quantity.
7. What about the After-Sales after I get it? How to install it?
A: Reach us anytime if you need our help, we have professional engineers here to service you 24/7 hours. We can provide detailed installation videos and pictures. Or send engineers team if necessary.
8. What's the warranty.
A: There's a 24 months warranty. If any parts of the machine break itself during the warranty period, not the artificial damage, please reach us, we will cover all the cost including the freight.
